Shelly Dimmer 1

PHYSICAL
Dimensions (LxWxH) 94x19x69 mm / 3.70x0.75x2.71 in
Weight 75 g / 2.7 oz
Ambient temperature -20 °C to 40 °C / -4 °F to 104 °F
Humidity 30 % to 70 % RH
Max. altitude 2000 m / 6562 ft
Screw terminals max torque 0.4 Nm / 3.5 lbin
Conductor cross section 0.5 to 2.5 mm2 / 20 to 14 AWG (green connectors) - 0.5 to 1.5 mm2 / 20 to 16 AWG (blue connector) (solid, strand-ed, and bootlace ferrules)
Conductor stripped length 6 to 7 mm / 0.24 to 0.28 in (green connectors) - 5 to 6 mm / 0.20 to 0.24 in (blue connector)
Power supply 110-240 V~ 50/60 Hz
Power consumption < 2 W
External protection max. 10 A, tripping characteristic B or C,6 kA interrupting rating, energy limiting class 3
SUPPORTED LOAD TYPES
HV LED lamps (Dimmable) 200 W
Dimmable electronic transformers 200 W
Incandescent Light bulbs 200 W
HV halogen lamp 200 W
Iron-core transformer 200 VA
Dimming type Trailing edge
RF band 2400 - 2495 MHz
Max. RF power < 20 dBm
Wi-Fi protocol 802.11 b/g/n
Wi-Fi operational range (depending on local conditions) up to 50 m / 160 ft outdoors up to 30 m / 100 ft indoors
Bluetooth protocol 4.2
Bluetooth operational range (depending on local conditions) up to 30 m / 100 ft outdoors up to 10 m / 33 ft indoors
CPU ESP32-D0WDQ6
Flash 8 MB
Schedules 20
Webhooks (URL actions) 20 with 5 URLs per hook
Scripting Yes
MQTT Yes
